Replaces 7-Inch Filter Socks

The patent pending Klir Fleece Filter Di-7 fits directly into most seven-inch filter sock chambers that automatically unroll new material as it gets clogged, removing suspended particles from an aquarium and producing crystal clear water. The easy-to-mount, magnetic water sensor detects when the fleece is dirty and automatically advances a new clean section, offering months of maintenance-free filtration.

The Klir filter is a direct replacement for filter socks on sumps with sock trays.Simply remove the filter sock from the sump and insert the Klir. As water passes through the Klir filter and the filtering material becomes saturated with waste, the water level will begin to rise. When the water makes contact with the optical sensor, a motor is activated to advance clean filtering material. As clean material is exposed, water can then flow freely, lowering the water level in the sock tray and deactivating the motor.

Klir’s Filtration Main Benefits:

1. Easy drop-in installation, no plumbing required. No additional sump space is needed.
2. Results in crystal clear water filtered down to 50-microns double the filtering capacity of most filter socks.
3. Waste is removed from the water column before it has time to break down, helping to maintain low nutrient parameters!
4. The constant chore of monitoring and swapping filter socks or other mechanical media every few days is eliminated for months at a time.* Once the filtering media is exhausted, replacing it is a snap and very economical.

*Life of fleece depends on many variables, including (but not limited to): biological load, feeding habits, and flow rate.

Klir Di-7 V2 Includes

• Klir 7″ Drop-In Automatic Fleece Filter
• 6.9″ Swappable Collar
• 7.55″ Swappable Collar
• V2 Smart Controller & Magnet-mount Sensor

• 50-Yard Roll of 50-Micron Fleece
• Activated Carbon Insert
• DC Geared Motor (DC12V/.6A)

Sump Requirements

A)Sump with sock tray (or use the Klir Filter Bracket [sold separately])

B)Capable of holding at least 1.5 inches of water above the sock tray

C)8.125 inches of available space below the filter sock tray

D)7.125-inch sump lid opening directly above the filter socks

WARRANTY

CoralVue, Inc. and Klir hereby guarantee this product to be free from defects in material and workmanship for a period of:

• 1 Year

Warranty is activated on the date of purchase.

This Standard Limited Warranty applies and is limited as follows:

• To the product only as long as it remains in the possession of the original purchaser.
• To the product that has not been subject to accident, misuse or abuse.
• To the product that has not been modified, altered, defaced, or had repairs made or attempted by other than CoralVue, Inc.
• That CoralVue be immediately notified in writing within ten (10) days of first knowledge of defect by owner or his agent.
• That CoralVue, Inc. shall be given first opportunity to make any repairs, replacements or corrections to the defective construction within a reasonable period of time.
• Under no circumstances shall CoralVue and/or the Manufacturer be liable by virtue of this warranty or otherwise for damage to any person or property whatsoever for any special, indirect, secondary or consequential damages of any nature however arising out of the use or inability to use because of the product defect.
